22-COMM-D — PowerFlex DeviceNet Adapter
PowerFlex Component Class, DeviceNet to DSI communication adapter
| Technical specifications for 22-COMM-D | |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 22-COMM-D |
| Manufacturer | Rockwell Automation |
| Description | DeviceNet communication adapter |
| Compatible Drives: | PowerFlex 40 |
| Communication Port | One (1) DSI connector; One (1) DeviceNet connector |
| Communication Protocol | DeviceNet; Drive Serial Interface (DSI) |
| Data Rate | 125K; 250K; 500K |
| No. of nodes: | 30 nodes |
| Converter tools: | Serial Converter (22-SCM-232) |
| Compatible PCI based adapters: | 1784-PCD, 1784-PCID, 1784-PCIDS, or 1770-KFD |
| LED indicators: | Three (3) LED indicators for connected drive, adapter, and network |
| DeviceNet cable: | Thin cable with outside diameter of 6.9 mm (0.27 in.) |
| Product Line | PowerFlex 70 |
| Product Type | DeviceNet-DSI Communication Adapter |
| Status Indicators | 3 |
| DeviceNet Connector | 5 pins |
| UPC | 662453981680 |
