20F1AGC205JN0NNNNN
PowerFlex Air Cooled 753 AC Drive
PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Type 12 / IP54, 205 Amps, 110kW ND, 90kW HD, 400 VAC, 3 PH, Frame 6, Filtered, CM jumper installed (preferred), None, Blank (No HIM)
| Technical specifications for 20F1AGC205JN0NNNNN | |
| Manufacturer | Allen Bradley |
| Product Type | Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AGC205JN0NNNNN |
| Weight | 32.06 lbs (14.54 kg) |
| Input Type | AC Input with Precharge, no DC Terminals |
| Enclosure | IP54, NEMA/UL Type 12 |
| Voltage Rating | 400V AC / 540V DC |
| Current Rating | 205 Amps |
| Power Rating | 110 kW |
| Filtering | Yes |
| Default CM Cap Connection | Jumper installed |
| Internal Resistor | No |
| Internal Transistor | No |
| Door Mounted HIM | No Door Mounted HIM |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -40 to 70 °C |
| Relative Humidity | 5 to 95% |
| Certifications | CE, ABS, EAC, KCC |
