1762-L40BXB
ALLEN-BRADLEY MicroLogix 1200 40 Point Controller
1762 MicroLogix 1200 System, MicroLogix 1200, 24V dc power, (20) standard 24V dc and (4) fast 24V dc digital inputs, (8) relay outputs, (7) standard 24V dc FET outputs, (1) fast 24V dc FET output
| Technical specifications for 1762-L40BXB | |
| Manufacturer | Allen Bradley |
| Product Type | Programmable Controller |
| Product Line | MicroLogix 1200 |
| Part Number | 1762-L40BXB |
| UPC | 612598279319 |
| Weight | 1.44 lbs (0.65 kg) |
| Power Supply | 24V dc ( -15%, +10%) Class 2 SELV |
| No. of Inputs | Twenty-Four (24) |
| Outputs | (8) Relay, (7) 24 Volt DC FET, and (1) High-Speed 24 Volt DC FET |
| Input Power | 24 Volts DC |
| No. of Outputs | Sixteen(16) |
| Inputs | (20) 24 Volt DC and (4) Fast 24 Volt DC |
| Input Circuit Type | 24 Volts DC Sink/Source |
| Power Supply Voltage | 100 to 240 Volts |
| Output Circuit Type | Relay / FET |
| Relay Contact Rating | 24-125VDC; 120-240VAC |
| Heat Dissipation | 21 Watts |
| Mechanical Cycles | 20,000,000 |
| Operating Frequency | 0 to 20 kHertz |
| Load Current | 10A, minimum |
| Ambient Operating Temp | 0 to 55 degrees Celsius |
| Power Supply Usage | 82 VA |
| Power supply inrush current | 120V ac: 25A for 8 ms; 240V ac: 40A for 4 ms |
