1762-L24BXB
ALLEN-BRADLEY MicroLogix 1200 24 Point Controller
1762 MicroLogix 1200 System, MicroLogix 1200, 24V dc power, (10) standard 24V dc and (4) fast 24V dc digital inputs, (5) relay outputs, (4) standard 24V dc FET outputs, (1) fast 24V dc FET output
| Technical specifications for 1762-L24BXB | |
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | MicroLogix 1200 |
| Part Number | 1762-L24BXB |
| UPC | 612598279302 |
| Weight | 1.00 lbs (0.45 kg) |
| Power Supply Usage | 40W |
| Power Supply | 24VDC |
| No. of Inputs | Ten (10) 24V dc; (4) fast 24V dc |
| No. of Outputs | Five (5) relay; Four (4) 24V dc FET; (1) high-speed 24V dc FET |
| Input Circuit Type | 24 VDC sink / source |
| Output Circuit Type | Relay; FET |
| Relay Contact Rating | 24-125VDC; 120-240VAC |
| Mechanical Cycles | 20000000 |
| Load Current | 10A, minimum |
| Communication Ports | One (1) 8-Pin mini-DIN serial port; |
| Supported Protocols | DF1, DH-485, ASCII, MODBUS |
| Ambient Operating Temp | 0 to 55 degrees Celsius |
| Power supply inrush current | 120V ac: 25A for 8 ms; 240V ac: 40A for 4 ms |
| Module Type | Programmable Controller |
| Inputs | (10) 24V DC and (4) Fast 24V DC |
| Outputs | (5) Relay, (4) 24V DC FET, (1) High-Speed 24V DC FET |
| Input Power | 24V DC |
| Power Supply Output | 400 or 350 milliamps |
| Operating Frequency | 0-20 kilohertz |
