1769-SDN
ALLEN-BRADLEY
Interface Scanner Module, DeviceNet, 125k Kbps, 64 Nodes
| Technical specifications for 1769-SDN | |
| Manufacturer | Allen Bradley |
| Product Type | Communication Module |
| Product Line | CompactLogix |
| Part Number | 1769-SDN |
| UPC | 612598287246 |
| Weight | 0.38 lbs (0.17 kg) |
| Module Type | DeviceNet Communication Module |
| Description | DeviceNet Scanner |
| Communication Port | One (1) DeviceNet |
| Series | A and B |
| Data Transfer speed | 125k bit/s 250k bit/s 500k bit/s |
| Solid Wire Size | 22 to 14 AWG |
| Mounting | DIN Rail; Panel |
| Stranded Wire Size | 22 to 16 AWG |
| Heat Dissipation | 440 mA at 5 Volts DC/2.2 Watts |
| Agency Certification | UL; CE; DeviceNet Foundation |
| Operating Temperature | 32°F to 140°F (0°C to 60°C) |
| UNSPSC | 32151705 |
| Storage Temperature | -40°F to +185°F (-40°C to +85°C) |
| Backplane Current | Series A: 450mA at 5V dc (2.25W) Series B: 500mA at 5V dc (2. 5W) |
| Humidity | 5% to 95% non-condensing |
