1794-IE8
Flex 8 Point Analog Input Module
1794 Flex, Flex Ex, Flex XT I/O System, Analog Input Modules, 8 Single-Ended Inputs
| Technical specifications for 1794-IE8 | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O High-Density Analog Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IE8 |
| UPC | 612598137817 |
| Weight | 0.25 lbs (0.11 kg) |
| Product Description | Flex IO High Density Analog Input Module |
| No. of inputs | Eight (8) Single Ended |
| Input type | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; 0 to 10 VDC |
| External DC supply, nom | 24V DC |
| External DC supply range | 10.0…31.2V DC (includes 5% AC ripple) |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | –40…85 °C (–40…185 °F) |
| Vibration | 5g @ 10 to 500 Hz |
| Inputs | 8 Single-ended |
| Resolution Voltage Current | 5.13 Amps/cnt |
| Conversion Rate | 256 seconds |
| Input Current Terminal | 4 to 20 mA |
| Input Voltage Terminal | +/- 10 Volts |
| FlexBus Current | 60 mA |
| External DC Power Supply | 60 mA at 24 Volts DC |
| Isolation Voltage | 50 Volts Continuous |
| Power Dissipation | 3.0W at 31.2 Volts DC |
| Thermal Dissipation | 10.2 BTU/hour at 31.2 Volts DC |
