1794-ID2
Flex 2 Point Distributed I/O Comb Module
1794 Flex, Flex Ex, Flex XT I/O System, Input Module, 2-Channel Incremental Encoder
| Technical specifications for 1794-ID2 | |
| Manufacturer | Allen Bradley |
| Product Type | Channel Incremental Encoder Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-ID2 |
| UPC | 612598184255 |
| Weight | 0.25 lbs (0.11 kg) |
| Inputs per Counter | 4 |
| On-state Voltage min. | 6V DC |
| On-state Voltage max. | 26.4V DC |
| On-state Current min. | 3mA @ 6V DC |
| On-state Current max. | 15mA @ 24V DC |
| Off-state Voltage max. | 3V DC |
| Counting Frequency | 100kHz max. |
| Isolation Voltage | 500V AC |
| Flexbus Current | 5mA @ 5V DC |
| Power Dissipation | 17.1 BTU/hr. @ 26.4V DC max. |
