1794-IA16
ALLEN-BRADLEY Flex 16 Point Digital Input Module
1794 Flex, Flex Ex, Flex XT I/O System, Input Module, 120VAC, 16 Inputs
| Technical specifications for 1794-IA16 | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O AC Digital Input Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IA16 |
| GTIN | 10612598179913 |
| Weight | 0.25 lbs (0.11 kg) |
| Product Family | Flex I/O |
| Product Description | AC Input Module |
| Keyswitch Position | 8 |
| ON state Voltage, min | 74VAC |
| ON state Voltage, max. | 132VAC |
| OFF state Voltage, max | 20VAC |
| Indicators | 16 Yellow status indicators |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Enclosure type rating | None (open-style) |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Inputs | 16 Nonisolated |
| On-state Current min. | 5.49 mA |
| On-state Current max. | 14.8 1mA |
| Off-state Current min. | 2.9 mA |
| Nominal Input Current | 12 mA at 120 Volts AC |
| Flexbus Current | 20 mA |
| Power Dissipation | 6.4 Watts at 132 Volts AC max. |
