1794-IB10XOB6
ALLEN-BRADLEY Flex 10 Input 6 Output Digital Module
| Technical specifications for 1794-IB10XOB6 | |
| Manufacturer | Allen Bradley |
| Product Type | Digital Combination I/O Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IB10XOB6 |
| UPC | 612598137770 |
| Weight | 3.00 lbs (1.36 kg) |
| Nominal On-State Input Voltage | 24 VDC |
| Input Type | Current Sink Inputs |
| Nominal On-State Output Voltage | 24 VDC |
| Output Type | Current Source Outputs |
| Number of Inputs | 10 |
| Number of Outputs | 6 |
| Nominal Input Impedance | 4.8 kilohms |
| Nominal On-State Input Current | 8 mA at 24 VDC |
| Nominal On-State Output Current | 2 A per Channel |
| Flexbus Current | 50 mA |
| IP Rating | None (Open) |
| Operating Temperature | -20°C to 55°C |
