1769-IF16V
ALLEN-BRADLEY CompactLogix 16 Pt A/I Voltage Module
| Technical specifications for 1769-IF16V | |
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | CompactLogix |
| Part Number | 1769-IF16V |
| UPC | 612598626793 |
| Weight | 0.19 lbs (0.09 kg) |
| Product Family | Compact I/O |
| Series | Compact I/O |
| No. of Inputs | 16 Single Ended Inputs |
| Module Type | Analog input Module |
| Power Supply Distance rating | 8 |
| No. of input | Sixteen (16) channels |
| Input Type | Analog Input |
| Input signal voltage range | ±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC |
| Wiring configuration | Single-ended |
| Voltage signal normal ranges | ±10V DC, 0 -10V DC, 0-5V DC, and 1-5V DC |
| Input signals | ±10V, 0-10V, 0-5V and 1-5V. |
| Communication Cable | 16 Point |
| Compatible Controllers | MicroLogix 1500; CompactLogix |
| Resolution | 16 bits (unipolar); 15-bits (bipolar) |
| Accuracy | ±0.35% full scale @ 25 °C (77 °F) |
| Analog to Digital Converter (ADC) | Sigma-Delta |
| Slot width | 1 |
| Enclosure Type | Open |
| Recommended cable | Belden™ 8761 (shielded) |
| Module location | DIN rail or panel mount |
| Backplane Current | 1.4 Amps at 24 Volts |
| Power Consumption | 33.6 Watts |
| Power Dissipation | 7.5 Watts |
| Current Draw | 190 mA @ 5.1 VDC; 70 mA @ 24 VDC |
