1769-IF16C
ALLEN-BRADLEY CompactLogix 16 Pt A/I Current Module
16 Channel Compact High- density Analog Current Input Module
| Technical specifications for 1769-IF16C | |
| Manufacturer | Allen Bradley |
| Product Type | Analog Input Module |
| Product Line | CompactLogix |
| Part Number | 1769-IF16C |
| UPC | 612598626786 |
| Weight | 0.50 lbs (0.23 kg) |
| No. of Inputs | 16 Single Ended Inputs |
| Power Supply Distance rating | 8 |
| Input current range | 0-21 mA |
| Current signal normal ranges | 0-20mA; 4-20 mA |
| Current signal full range | 0-21 mA; 3.2 – 21 mA |
| Compatible Controllers | MicroLogix 1500; CompactLogix |
| Slot width | 1 |
| Recommended cable | Belden™ 8761 (shielded) |
| Module Type | 16 Point Analog Current Input Module |
| Input Type | Analog Input |
| Communication Cable | 16 Point |
| Enclosure Type | Open |
| Backplane Current | 1.4 Amps at 24 Volts |
| Power Consumption | 33.6 Watts |
| Power Dissipation | 7.5 Watts |
| Isolation Voltage | 30 Volts DC |
