2711P-T6M5D8
Description: The 2711P-T6M5D8 is a PanelView Plus 6 Operator terminal. It is part of the Visualization product catalog that is manufactured by Allen-Bradley. It functions as a Human Machine Interface (HMI), featuring a monochrome display measuring 5.7 inches with a resolution of 320 x 240 pixels. It comes with a Touchscreen operator interface; RS232 communication port supporting DF1 protocol; USB ports for attachment of peripheral devices such as keyboard, mouse, and USB removable drive. This terminal operates at an input supply voltage of 18-30 VDC, 24 VDC, nominal.
Technical Specifications for 2711P-T6M5D8
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711P-T6M5D8 |
| Manufacturer: | Rockwell Automation |
| Product Line | Panelview 6 Plus |
| Brand: | Allen-Bradley |
| Display Size | 5.5-inch |
| Product Family: | PanelView Plus 6 Terminals |
| Display Color | Monochrome |
| Product Type: | Operator Terminals |
| Input Type | Touchscreen |
| Part Number: | 2711P-T6M5D8 |
| Communication | RS-232 |
| Input Type: | Touch |
| Input Power | 18-30 VDC |
| No. of Function keys | Ten (10) F1-F10 |
| Real Time Clock (RTC) | Battery-backed clock |
| Memory | 256 MB RAM |
| Clock accuracy | +/-2 minutes per month |
| Backlight | Non-replaceable |
| Display Type: | Grayscale TFT LCD |
| Communication Cable | 2711-NC13 |
| Display Area: | 115 x 86 mm (4.5 x 3.4 in.) |
| Shipping Weight | 6 lbs. |
| Resolution: | 320 x 240 pixels |
| Shipping Dimensions | 14 x 11 x 8 in |
| Integrated memory: | 256 MB RAM; 512MB Non-volatile memory |
| Series | Series A and Series B |
| Communication ports: | DF1; DH-485 |
| Communication protocols | DF1; DH-485 |
| Input Voltage range: | 18-30 VDC; 24 VDC, nominal |
| Operating system | Windows CE 6.0, standard |
