2711P-T15C22D9P
Description: The Allen-Bradley 2711P-T15C22D9P is a PanelView Plus 7 Performance operator terminal. This Human Machine Interface (HMI) device is powered by an external supply voltage of 18-32VDC. It has a 15-inch Color active matrix, thin-film transistor (TFT) LCD screen with embedded Touchscreen operator interface. It has a variety of communication ports such as, Two (2) Ethernet and Three (3) USB ports. It has a Windows CE 6.0 Extended software.
Technical Specifications for 2711P-T15C22D9P
| Display Size | 15 in. |
| Brand | Allen-Bradley |
| Manufacturer: | Rockwell Automation / Allen-Bradley |
| Product Family: | PanelView Plus 7 Performance terminals |
| Product Type: | PanelView Plus 7 15-inch Performance Terminals |
| Operator Input: | Touch |
| Touch screen: | Analog resistive touchscreen |
| Actuation rating: | 1 million presses |
| Operating force: | 100 grams |
| Display Type: | Color active-matrix TFT |
| Display Area: | 304 x 228 mm (12.0 x 9.0 in.) |
| Resolution: | 1024 x 768 XGA, 18-bit color graphics |
| Backlight: | White light-emitting diode, solid state Life: 50,000 h min at 40 °C (104 °F) to half-brightness, backlight is not replaceable |
| Application memory: | 1GB system; User memory 512 MB |
| Communication ports: | Two (2) Ethernet, Three (3) USB host |
| Input Voltage range: | 18-30 VDC |
| Operating System: | Windows CE with Extended Features and MS Office Viewers (includes FTP, VNC client server, ActiveX controls, PDF reader, third-party device support) |
| Touch: | Analog resistive Actuation: 1 million presses; operating force: 100 g |
| System Memory: | 512 RAM, 512 MB nonvolatile memory (approx. 80 MB free user memory) |
| Power Consumption: | 50 W max (2.1 A at 24V DC) |
| Part Number/Catalog No. | 2711P-T15C22D9P |
| Product Line | Panelview Plus 7 |
| Input Type | Touchscreen |
| Display Color | Color |
| Memory | 512 Mb |
| Input Voltage | 24 VDC |
| Backlight | LED |
| Weight | 8.14 LBS |
| UPC | 885630844718 |
| UNSPSC | 43211903 |
