1794-OE4XT
1794 Flex, Flex Ex, Flex XT I/O System
1794 Flex, Flex Ex, Flex XT I/O System, Analog Output Module, 4 Point, Flex XT
| Technical specifications for 1794-OE4XT | |
| Manufacturer | Allen Bradley |
| Product Type | High-Density Analog Module |
| Part Number | 1794-OE4XT |
| UPC | 612598592555 |
| Weight | 0.25 lbs (0.11 kg) |
| Series | Flex I/O 1794 |
| Extended Temperature Module | Supported |
| Number of Outputs | 4 |
| Output Type | Single-Ended, Non-Isolated Outputs |
| Nominal Output Voltage Range | -10 to 10V |
| Maximum Output Current Range | 0 to 20 mA |
| Resistive Load | 15 to 750 ohms at 24V DC |
| External DC Power Supply Nominal Voltage | 24V DC |
| External DC Power Supply Voltage Range | 19.2 to 31.2V DC |
