Allen-Bradley 1761-L32BWA MicroLogix1000 32 Point Controller 1761 L32BWA
| Technical specifications for 1761-L32BWA | |
| Manufacturer | Allen Bradley |
| Product Type | Programmable Logic Controller (PLC) |
| Product Line | MicroLogix 1000 |
| Part Number | 1761-L32BWA |
| UPC | 662468368711 |
| Weight | 2.00 lbs (0.91 kg) |
| I/O Count | 32 points |
| Memory | 1 K EEPROM composed of approximately 737 instruction words and 437 data words. |
| Input Type | 24 Volts DC |
| Communication port | RS232 |
| Safety Feature | Master Control Relay |
| Protocol | DF1 |
| Digital Outputs | 12 Contact Outputs |
| Isolation Voltage | 1500 Volts DC |
| No. of Inputs | Twenty (20) sinking and sourcing inputs |
| Communication | RS-232 Port |
| Input Voltage Type | 14 – 30V dc |
| Output Type | Twelve (12); Relay |
| Mounting | DIN Rail/mounting screws |
| Power Supply | 120/240 Volts AC |
| Inrush Current | 30A for 4 ms |
| Operating Frequency | 47-63 Hz |
| Product Lifecycle Status* | Discontinued/Obsolete |
| Input Power | 16 VA @ 120 VAC; 22 VA @ 240 VAC |
