1. Basic Model & Ordering Info
表格
| Parameter | Value |
|---|---|
| Model Number | DCS550‑S02‑0300‑05‑00‑00 |
| ABB Part Code | 3ADT218466R0014 |
| Drive Type | 4‑Quadrant (Full Regenerative, Double Bridge) |
| Control Mode | Armature & Field Control, Digital DC Drive |
| Enclosure | Open Chassis (IP00) |
| Cooling | Fan Cooled (115/230 VAC Fan Supply) |
| Integrated Features | 3‑Phase Field Exciter, Built‑in Winder Macros, PID, Adaptive Programming |
2. AC Input (Mains) Ratings
表格
| Parameter | Value |
|---|---|
| Input Voltage (3AC) | 230 … 525 VAC |
| Voltage Tolerance | −15% / +10% |
| Input Frequency | 45 … 65 Hz (50 / 60 Hz Nominal) |
| Input Phase | 3‑Phase |
| Fan Supply (Single‑Phase) | 115 / 230 VAC (for 135–520 A Models) |
3. DC Armature Output Ratings (Main Power)
表格
| Parameter | Value |
|---|---|
| Rated Armature Current (Idc, Cont) | 300 A (Continuous) |
| Peak Armature Current | 750 A (250% × 60 s) |
| Medium Overload | 450 A (150% × 10 min) |
| Max DC Armature Voltage (4‑Q) | 480 VDC @ 460 VAC Input; 522 VDC @ 525 VAC Input |
| Rated DC Power (Typical) | 147 kW (@ 490 VDC × 300 A) |
| Speed Regulation (Encoder) | ±0.01% |
| Speed Regulation (Armature Voltage) | ±0.1% |
| Current Loop Bandwidth | >1000 Hz |
| Field Weakening Range | 1:10 |
4. Field Exciter (Integrated 3‑Phase)
表格
| Parameter | Value |
|---|---|
| Rated Field Current (If) | 35 A (Max, Adjustable) |
| Field Voltage Range | 0 … 420 VDC (Depends on Mains) |
| Control | Digital, Programmable, Separate Field Regulation |
5. Power & Efficiency
表格
| Parameter | Value |
|---|---|
| Typical Efficiency | 98% (at Full Load) |
| Power Factor | >0.95 (with Line Reactor) |
| Regeneration | Full 4‑Quadrant (Energy Back to Mains) |
6. Physical & Environmental
表格
| Parameter | Value |
|---|---|
| Dimensions (H × W × D) | 370 × 270 × 270 mm |
| Net Weight | 16 kg |
| Operating Temperature | 0 … +40 °C |
| Storage Temperature | −25 … +70 °C |
| Altitude Derating | 1% per 100 m above 1000 m |
| Humidity | 5 … 95% RH (Non‑Condensing) |
7. Control & Interfaces
表格
| Parameter | Value |
|---|---|
| Control Signals | Digital I/O, Analog I/O (±10 V / 4–20 mA) |
| Communication | PROFIBUS DP, PROFINET, EtherCAT, Modbus RTU (Options) |
| Feedback | Tachogenerator, Encoder (Incremental / Absolute) |
| Protection | Overcurrent, Overtemperature, Overvoltage, Undervoltage, Field Loss, Earth Fault |
